SoundCraft Ui16 User Guide

Ui12, Ui16 User Manual
5.0: CHANNEL EDIT
CHANNEL EDIT
5.0: CHANNEL EDIT
The EDIT page is the basic access point for channel-based signal processing: EQ, dynamics, and FX
and auxiliary sends. The actual processing and options available depend on the channel type.
The selected channel strip will be shown on the left of the EDIT screen. In the phone software, the
default EDIT page is a via-point for more detailed views and also offers access to basic channel
parameters such as pan/balance, phase, phantom power, and more.
EDIT PAGE ACCESS
The EDIT page is available from a number of different Ui Software screens. To select the EDIT page directly
either click/tap the EDIT button in the top-line navigation bar (tablet software) or select the EDIT menu item
(phone software).
Alternatively you can:
• Double click/tap on a channel fader cap to navigate to channel EDIT mode EQ tab.
• Double click/tap on channel label (channel types: INPUT, LINE IN, PLAYER, SUB GROUP, AUX) to navigate to
selected channel EDIT page DYN tab.
• Double click/tap on a channel label (channel type: FX RETURN) to navigate to selected channel EDIT page FX
tab (Global FX parameters).

SoundCraft Ui16 Specifications

General

Channels	16
Mic Preamps	8
USB Playback	Yes
Built-in Wi-Fi	Yes
XLR Inputs	8
Aux Sends	4
Phantom Power	Yes
Sampling Rate	48 kHz
Bit Depth	24-bit
Ethernet Port	1
Remote Control	Remote control via HTML5-compatible browser
RCA Inputs	2
Control	Control via any device with a web browser
Wi-Fi	Built-in Wi-Fi
Microphone Preamps	8
USB Audio Interface	2-channel recording/playback
Monitor Outputs	2
Aux Outputs	4
Power Supply	Internal
USB	USB playback and recording
Dimensions	177 x 482 x 89 mm
Weight	3.9kg (8.6 lbs)
