SoundCraft Ui16 User Guide

Ui12, Ui16 User Manual
10.1: NETWORK CONFIG
SETTINGS > NETWORK CONFIG
10.1: NETWORK CONFIG
The Ui Cong page allows you to enable/disable and edit settings for Hotspot wireless connection to
the Ui hotspot), WiFi (connection to an existing WiFi network), and LAN (wired connection via Ethernet).
There is also an Administration password change page, and a summary ‘Network State’ page.
IMPORTANT: The default administration user name is ‘admin’ and the default administration password is ‘admin’.
You will be asked for these when you touch the CONFIG button.
You can change the password using the Administrator Password page once you are in the CONFIG area.

SoundCraft Ui16 Specifications

General

Channels	16
Mic Preamps	8
USB Playback	Yes
Built-in Wi-Fi	Yes
XLR Inputs	8
Aux Sends	4
Phantom Power	Yes
Sampling Rate	48 kHz
Bit Depth	24-bit
Ethernet Port	1
Remote Control	Remote control via HTML5-compatible browser
RCA Inputs	2
Control	Control via any device with a web browser
Wi-Fi	Built-in Wi-Fi
Microphone Preamps	8
USB Audio Interface	2-channel recording/playback
Monitor Outputs	2
Aux Outputs	4
Power Supply	Internal
USB	USB playback and recording
Dimensions	177 x 482 x 89 mm
Weight	3.9kg (8.6 lbs)
