SoundCraft Ui16 User Guide

Ui12, Ui16 User Manual
10.1.1: HOTSPOT
SETTINGS > NETWORK CONFIG > HOTSPOT
10.1.1: HOTSPOT SETTINGS
Use the Save/Update button to save Hotspot settings.
IMPORTANT: You must recycle the Ui power (turn the unit off and on) for settings to take effect.
The Ui has it’s own hotspot, so it can create it’s own network so other devices can connect to it and
access the software in it’s built-in webserver. Select the Hotspot Conguration menu in Network Cong
to edit the Hotspot settings.
Hotspot
Enabled / Disabled
Enable or disable the UI’s own Hotspot. Please note, if the Hotspot is disabled you will need to connect to the Ui via
either an existing Wi-Fi network, or a wired LAN connection (Ethernet).
SSID (Service Set Identier)
Text Entry
This is the name of the Ui Hotspot. The default is ‘Soundcraft Ui’
Wireless Regulatory Domain
Region Selection
Select the correct region - you current location. This will help select the correct channel selection.
Channel
Channel Selection
A number of channels are available within the Wi-Fi spectrum, depending on the Regulatory Domain. There is
third-party software available to help you select a local Wi-Fi channel.
Security
None / WPA2
Choose either no security, or WPA2 (Wi-Fi Protected Access II) protection. IN the latter case, you will have to choose
a password.

SoundCraft Ui16 Specifications

General

Channels	16
Mic Preamps	8
USB Playback	Yes
Built-in Wi-Fi	Yes
XLR Inputs	8
Aux Sends	4
Phantom Power	Yes
Sampling Rate	48 kHz
Bit Depth	24-bit
Ethernet Port	1
Remote Control	Remote control via HTML5-compatible browser
RCA Inputs	2
Control	Control via any device with a web browser
Wi-Fi	Built-in Wi-Fi
Microphone Preamps	8
USB Audio Interface	2-channel recording/playback
Monitor Outputs	2
Aux Outputs	4
Power Supply	Internal
USB	USB playback and recording
Dimensions	177 x 482 x 89 mm
Weight	3.9kg (8.6 lbs)
