SoundCraft Ui16 User Guide

Ui12, Ui16 User Manual
5.4: DYNAMICS
CHANNEL EDIT > DYNAMICS
5.4: DYNAMICS
The Ui dynamics section is a comprehensive audio compressor/limiter and gate section. Basically, a
compressor reduces the level of the audio once it passes a particular threshold. You can set the Ui
Compressor Release parameter to ‘Inf’ (Innite) to create a Limiter. An audio gate uses a threshold to
determine its ‘open ‘ (above Threshold) or ‘closed’ (below Threshold) status. When a gate is closed,
the signal level is reduced, or cut completely. A gate can, for example, be used to reduce ambient
noise picked up by a microphone when the source (instrument/voice) is not active.
THRESHOLD
Adjust the Threshold of the compressor
The tablet version of the software includes a horizontal THRESHOLD fader. You can drag the orange ‘T’ ball in the
dynamics graphic in both phone and tablet versions.
GATE
Adjust the Threshold of the gate
When the audio signal level falls below this threshold, the signal is attenuated. The gate threshold is depicted in
the dynamics graphic as a darkened horizontal zone.
RATIO
Adjust the compression ratio
This determines how much the compressor attenuates the audio after the threshold level has been passed.
An infinite (inf) RATIO setting causes the compressor to become a limiter.

SoundCraft Ui16 Specifications

General

Channels	16
Mic Preamps	8
USB Playback	Yes
Built-in Wi-Fi	Yes
XLR Inputs	8
Aux Sends	4
Phantom Power	Yes
Sampling Rate	48 kHz
Bit Depth	24-bit
Ethernet Port	1
Remote Control	Remote control via HTML5-compatible browser
RCA Inputs	2
Control	Control via any device with a web browser
Wi-Fi	Built-in Wi-Fi
Microphone Preamps	8
USB Audio Interface	2-channel recording/playback
Monitor Outputs	2
Aux Outputs	4
Power Supply	Internal
USB	USB playback and recording
Dimensions	177 x 482 x 89 mm
Weight	3.9kg (8.6 lbs)
