10.0: SETTINGS
SETTINGS
10.0: SETTINGS
The SETTINGS page allows the user to manage basic setup congurations, network parameters
(including the password setting for the WiFi access point), GUI preferences, and access permissions
on a per-user basis. Phone and tablet software versions display the settings in slightly different forms,
but al are accessible on either platform. The sub headings used in this section refer to the Tablet
software.
GLOBAL
HEADPHONES OUT
MASTER/SOLO, AUX
Choose a source for the headphones. MASTER/SOLO is normal operation (either Master stereo output or Solo bus if
an AFL or PFL is selected). AUX selects the highest pair of Aux buses as the source (3/4 for Ui12 and 5/6 for Ui16).
SOLO ROUTING
HEADPHONES, MASTER + HP
When channels are soloed, either route the solo bus to Headphones only, or to both
Headphones and the Master Output.
SOLO MODE
SINGLE, MULTIPLE
SINGLE deactivates any previous solo when a new one is pressed. MULTIPLE is an accumulative solo mode
(previous solos are not deactivated).
RECORD MODE
32-bit, 24-bit, 16-bit
Choose a sample rate for the media recording function.
LOCAL
MASTER LOCK
ON, OFF
When ON, the Master Channel fader is locked in place. Other parameters are still changeable.

SoundCraft Ui16 Specifications

General

Channels	16
Mic Preamps	8
USB Playback	Yes
Built-in Wi-Fi	Yes
XLR Inputs	8
Aux Sends	4
Phantom Power	Yes
Sampling Rate	48 kHz
Bit Depth	24-bit
Ethernet Port	1
Remote Control	Remote control via HTML5-compatible browser
RCA Inputs	2
Control	Control via any device with a web browser
Wi-Fi	Built-in Wi-Fi
Microphone Preamps	8
USB Audio Interface	2-channel recording/playback
Monitor Outputs	2
Aux Outputs	4
Power Supply	Internal
USB	USB playback and recording
Dimensions	177 x 482 x 89 mm
Weight	3.9kg (8.6 lbs)
