SoundCraft Ui16 User Guide

4.3: AUX SENDS
CHANNELS > AUX SENDS
4.3: AUX SENDS
Ui12, Ui16 User Manual
PRE/POST (Tablet software)
Switch input channel’s Aux contribution between PRE and POST sources
AUX channels are pre-fader by default, meaning the volume faders on the MIX page do not aect the aux levels.
Press the PRE button to change individual channels to POST fader. A long press on the PRE/POST button opens a
dialog for ALL CHANNELS TO PRE or POST.
AUX SEND MUTE (Tablet software)
Mute the input channel’s contribution to this aux mix.
Separate to the normal input channel mute - only aects contribution to the selected aux mix.
M-AUX / COPY MIX
Copy the main mix to this aux mix
This button copies the fader positions from the MIX page and moves all aux send faders to the same position on
the AUX SENDS page. This is a handy starting point for an AUX mix rather than starting from all faders down.
You can press this button at any time if you want your monitor mix fader positions to resemble the MAIN mix. For
safety, user confirmation is required.

SoundCraft Ui16 Specifications

General

Channels	16
Mic Preamps	8
USB Playback	Yes
Built-in Wi-Fi	Yes
XLR Inputs	8
Aux Sends	4
Phantom Power	Yes
Sampling Rate	48 kHz
Bit Depth	24-bit
Ethernet Port	1
Remote Control	Remote control via HTML5-compatible browser
RCA Inputs	2
Control	Control via any device with a web browser
Wi-Fi	Built-in Wi-Fi
Microphone Preamps	8
USB Audio Interface	2-channel recording/playback
Monitor Outputs	2
Aux Outputs	4
Power Supply	Internal
USB	USB playback and recording
Dimensions	177 x 482 x 89 mm
Weight	3.9kg (8.6 lbs)
