SoundCraft Ui16 User Guide

Ui12, Ui16 User Manual
5.2: PARAMETRIC EQ
CHANNEL EDIT > PARAMETRIC EQ
5.2: PARAMETRIC EQ
H - HPF BALL
Draggable graphic ‘ball’ for High Pass Filter control
Drag this graphic element to control. Left/Right adjusts Cut-O frequency. Double-click/tap to reset.
DE-ESSER FREQUENCY
Fader control of De-Esser Frequency
Determines the centre frequency of the De-Esser dynamic filter - the frequency on which the de-essing process is
focussed. To access the De-Esser fader controls in phone software, tap the DE-ESSER SETUP button.
DE-ESSER THRESHOLD
Fader control of De-Esser Threshold
De-Esser threshold is the level at which the De-Esser starts to attenuate the ‘ess’ band. To access the De-Esser
fader controls in phone software, tap the DE-ESSER SETUP button.
DE-ESSER RATIO
Fader control of De-Esser Ratio
De-Esser Ratio is the amount by which the ‘ess’ band is attenuated when the audio level crosses the Threshold. To
access the De-Esser fader controls in phone software, tap the DE-ESSER SETUP button.
EQ FREQUENCY
Fader control of EQ band Frequency
Fader control of EQ is only available with tablet software. Double-click/tap to reset.

SoundCraft Ui16 Specifications

General

Channels	16
Mic Preamps	8
USB Playback	Yes
Built-in Wi-Fi	Yes
XLR Inputs	8
Aux Sends	4
Phantom Power	Yes
Sampling Rate	48 kHz
Bit Depth	24-bit
Ethernet Port	1
Remote Control	Remote control via HTML5-compatible browser
RCA Inputs	2
Control	Control via any device with a web browser
Wi-Fi	Built-in Wi-Fi
Microphone Preamps	8
USB Audio Interface	2-channel recording/playback
Monitor Outputs	2
Aux Outputs	4
Power Supply	Internal
USB	USB playback and recording
Dimensions	177 x 482 x 89 mm
Weight	3.9kg (8.6 lbs)
