Troubleshooting
91369 Service Manual 5-10
Video Menu
Touch the v key in the Individual Diagnostic menu to display the Video menu.
Figure 5-8: Video Menu
The following keys are available in the Video menu:
r — Returns to the Individual Diagnostics menu.
v — Runs the power-ON video diagnostic.
d — Displays the registers.
i — Runs an interactive video diagnostic, which displays red, green, blue, white, and black screens, for five
seconds each. Inspect the screen for faulty pixels.
Error Log
For troubleshooting intermittent problems, the monitor maintains an error log for both recoverable and non-
recoverable errors in its battery-backed, non-volatile memory. All diagnostics failures are logged in the error
log.
Most errors relate to the CPU PCBA, but some errors may be caused by the parameter module or software
errors. For example, a particular sequence of key strokes that always produces the same error code could be
a software problem.
Displaying the Error Log
Before using the Error Log, ensure that all other procedures have been followed, including elimination of
operator errors, testing of voltages, correction of display faults, diagnostic testing, cabling/connector repairs,
software compatibility, etc.
From the Boot menu (refer to Boot Menu on page 5-3), touch E to access the Error Log Functions menu,
then d to view the Error Log.
VIDEO MENU
r - Return to Previous Menu
v - Video Diagnostic *
d - Display Registers
i - Interactive Video Diagnostic
rvdi
—>
