Appendix A — Electromagnetic Compatibility
91369 Service Manual A-2
Electromagnetic Immunity
Note:
The monitor is intended for use in the electromagnetic environment specified below. The customer, or
user, of the monitor should ensure that it is used in such an environment
.
Immunity Test IEC 60601 Test Level Compliance Level
Electromagnetic
Environment
Electrostatic
discharge (ESD)
IEC 61000-4-2
±6 kV contact
±8 kV air
8 kV contact
15 kV air
Floors should be wood,
concrete, or ceramic tile. If
floors are covered with
synthetic material, the
relative humidity should be at
least 30%.
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV for power supply
lines
±1 kV for input/output
data lines
±2 kV for power supply
lines
±1 kV for input/output
data lines
Mains power quality should
be that of a typical
commercial or hospital
environment.
Surge
IEC 61000-4-5
±1 kV differential mode
±2 kV common mode
1 kV differential mode
2 kV common mode
Mains power quality should
be that of a typical
commercial or hospital
environment.
Voltage dips,
short
interruptions,
and voltage
variations on
power supply
input lines
IEC 61000-4-11
<5% U
T
(>95% dip in U
T
for
0.5 cycle)
40% U
T
(60% dip in U
T
for
5 cycles)
70% U
T
(30% dip in U
T
for
25 cycles)
<5% U
T
(>95% dip in U
T
for
5 seconds)
<5% U
T
(>95% dip in U
T
for
0.5 cycle)
40% U
T
(60% dip in U
T
for
5 cycles)
70% U
T
(30% dip in U
T
for
25 cycles)
<5% U
T
(>95% dip in U
T
for
5 seconds)
Mains power quality should
be that of a typical
commercial or hospital
environment.
The monitor automatically
switches to internal battery
operation during mains
power interruptions.
Power
frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
3 A/m 60 A/m
Power frequency magnetic
fields should be at levels
characteristic of a typical
location in a typical
commercial or hospital
environment.
Note: U
T
is the AC mains voltage prior to application of the test level. All power line immunity tests
were performed at 120 VAC/60 Hz and 230 VAC/50 Hz.
