91369 Service Manual 1-3
Introduction
Physical Dimensions
Electrical Specifications
Designed for continuous operation. Requires outlet with ground (Protective Earth) conductor. Designated
Class I by applicable electrical safety standards.
AC Line Requirements
Environmental Requirements
Regulatory Approvals
CSA certified. Meets IEC60601-1, UL60601-1, and CSA C22.2 No. 601.1 for electrical safety. CE marked in
accordance with the Medical Device Directive 93/42/EEC.
Assembled weight 10.0 pounds (4.6 kg)
Dimensions
8.3 (H) × 11.7 (W) × 6.2 (D) inches
(21.1 × 29.7 × 15.8 cm)
AC input voltage range 100 to 240 VAC
AC input current 1.0 A
AC input frequency range 50 – 60 Hz
Operating temperature 0° to 50° C
Humidity (operating) 10% to 95% relative humidity, non-condensing
US
US
