Equipment Required
Electrical Safety Analyzer, Fluke model 232D or equivalent.
These tests should be performed according to the hospital’s scheduling requirements, at least annually or after
repair or modification.
Warning:
Before starting safety tests, ensure that no patient is connected to the device under test. If safety
tests must be performed on equipment currently monitoring a patient, obtain permission to
disconnect the cables from the monitor and patient.
Note:
All tests must be performed according to the safety analyzer’s operations manual, and any local
requirements.
Ground Resistance
1 Attach the power cord to the monitor under test, then measure the resistance from the AC power cord third
wire ground to a chassis location, such as the equipotential post on the rear of the monitor.
2 Verify that the resistance is less than 500 milliohms (0.5 ohms).
Chassis Leakage Current Tests
1 Plug the leakage analyzers into mains power.
2 Plug the equipment into the analyzer’s AC receptacle.
3 Verify that the leakage current from the chassis to ground is less than the values in Table 2.
Table 1: Summary of Standards for Medical Monitoring Equipment
International Mains to
Chassis Leakage
U.S. (120 V) Mains to
Chassis Leakage
Mains Resistance
100 μA - normal condition, ground
attached (AC connector to chassis)
300 μA - normal condition, ground
attached (AC connector to chassis)
500 milliohms*
500 μA - single fault condition, open
ground or reverse polarity
300 μA - single fault condition, open
ground or reverse polarity
500 milliohms*
* Measured from the AC Power cord third wire ground to the most distant ground attachment
