91369 Service Manual 2-5
Setup
Caution:
For continued electromagnetic interference (EMI) radiation compliance, use only cables that have
been tested and approved by Spacelabs Healthcare. Refer to
Table 2 on page 6-3 for all cable part
numbers.
Table 1: Rear Panel Cables
Rear Panel
Connection
Description Part Number

Cable, Serial I/O (RS-232) As required

Cable, Video, DB15HD Male to DB15HD Male,
1.8 m (6 feet)
012-0593-00

Cable, SDLC As required

Cable, Monitor to Module Housing, 0.61 m (2 feet) 012-0532-02

Cable, Monitor to Module Housing, 1.22 m (4 feet) 012-0532-04

Cable, Monitor to Module Housing, 2.44 m (8 feet) 012-0532-08

Cable, Monitor to Module Housing, 3.05 m (10 feet) 012-0532-10
