Spacelabs 91369 - Page 18

Setup
91369 Service Manual 2-10
Figure 2-7: Alarm 1 (medium priority) relay schematic
Figure 2-8: Alarm 2 (low priority) relay schematic
ALMON
+12 V
+5 V
relay
7
5
6
4
8
10
9
common
NC
NO
140 mA
Relay maximum ratings:
28 V AC/DC
0.25 A
11
GND
GND
GND
GND
ALMON
+12 V
+5 V
relay
13
14
12
4
8
10
9
common
NC
NO
140 mA
Relay maximum ratings:
28 V AC/DC
0.25 A
11
GND
GND
GND
GND
