Never force the installaon of any parts. All parts t correctly without
force. If parts don’t seem to t, remove all parts and repeat assembly.
a. Lubricate seal of beater
b. Insert beater assembly into cylinder,
c. Rotate to lock in place, make sure the
beater fully inside.
a. Install internal and front drip trays.
b. If machine will be le unused, install air
tube and place hopper lid on top;
otherwise, set air tube aside unl aer
machine has been primed.
a. Place O-rings on draw valve; coat all ring
areas with Spaceman lubricant.
b. Insert draw valve into dispensing door.
c. Install dispensing handle. Insert le part
rst.
d. Snap star cap onto boom of dispensing
door.
e. Install door gaskets and beater guide.
f. Install dispensing door assembly.
g. Install dispensing door screws.
