— 21.02.2020 —
7.3 Cleaning the UV optics light inlet window
Warning of hazardous voltage!
When the
plasma generator is switched on, there is a risk of electric shock if the
Shut down the plasma generator when working on the spark stand.
To clean the light inlet window, proceed as follows:
1. Turn off the plasma generator.
2. Loosen the two screws (1) of the
light inlet window (2).
3. Remove the light inlet window.
Direct contact with the
optical surfaces must be
avoided.
Fig. 8
4. Unscrew the fixing ring (3) of the
light entry window (2) using the
auxiliary tool (1).
Fig. 9
Fig. 10
