PARTS LIST  TANK OUTLET VALVES
SP1613 LONG STROKE TANK OUTLET VALVE
SP1613 LONG STROKE TANK OUTLET VALVE
SP1613 LONG STROKE TANK OUTLET VALVES
ITEM PART NUMBER DESCRIPTION KIT
1
SP110
SP120
SP130
Actuator (N.O.)
Actuator (N.C.)
Actuator (A/A)
2 SP13Z-2.5 Bonnet Clamp
3 SP161-7-Size-3 Bonnet
** SP161-4 Spool Piece
4 SP160-7-1.5-9 Spring Clip ○
5
SP13HC-2.5
SP13HC-3
SP13HC-3.5
SP13HC-4
Clamp for 1.5” Valve
Clamp for 2” Valve
Clamp for 2.5” Valve
Clamp for 3” Valve
6
SP40B-2.5
SP40B-3
SP40B-3.5
SP40B-4
Body Gasket for 1.5” Valve
Body Gasket for 2” Valve
Body Gasket for 2.5” Valve
Body Gasket for 3” Valve
○
7 SP10-6 Stem O-Ring ○
8
SP161-7-Size-2E
SP160-7-Size-2V
Plug and Stem (EPDM)
Plug and Stem (Viton)
9 SP163R-7-Size-1 Tang. Right Tee Body
10 SP163L-7-Size-1 Tang. Left Tee Body
11 SP163S-7-Size-1 Straight Tee Body
12 SP163F-7-Size-1 Flange Tee Body
○ INCLUDED IN SP120-RBK-SIZE VALVE SERVICE KIT
