Operator Manual - Spider ILD02 SG
22 / 51 rev. 01-01-04-2011
9. PREPARING THE MACHINE
9.1 MACHINE DELIVERY TO A DEALER
OR RETAILER
From the manufacturer the machine is
delivered filled with engine oil and
Hydraulic oil but without gasoline in the
tank.
The training of the operator should take place during
the installation of the product.
The mower may be delivered on a wooden pallet or
in a crate.
To take the mower off the pallet/crate:
Place the palette with the mower on a level
surface
Carefully remove the upper boards of the crate
and take out all accessories & the remote
control. Disassemble the side boards of the
crate
Release the attachment fastening the mower
to the pallet, remove transportation wrapping.
Recycle these wraps.
Thoroughly examine the mower for possible
damage and missing parts from the delivery. If
necessary, contact the transporting company
with your claim.
Before driving down from the pallet raise the
mowing mechanism to the upper position (this
can be done without starting the engine)
Place boards in front of the wheels in the
direction, in which you expect to drive the
mower from the pallet to the ground. Put at
least 5 litres/1.2 gallon of fuel to the tank and
attach cables onto the battery. While starting,
follow instructions in chapter 5.
The aerial must be attached to the mower
After starting the engine set the speed
controller on the transmitter to the (L)/turtle
symbol – lower driving speed
Slowly move the forward/reverse joystick to
correspond with the direction you want to
move the mower. The arrow on the wheel legs
indicates forward.
Slowly drive down to the ground and stop the
engine
While unpacking, assembling and preparing
the mower, do not engage the mower blade.
NOTICE: if you have a lifting device with a sufficient
lifting capacity available, place the lifting hooks/eyes
on spots marked with the symbols of chain, lift the
load by about 0.15 m / 6 inches, move the pallet
away from the mower and lower the machine to the
ground.
NOTICE: There may not be enough fuel in the fuel
system when starting for the first time and you may
need to repeat the starting several times. Starting
period must not exceed 3 seconds. There must be a
pause of at least 20 seconds between all attempts to
start the engine.
Parts of delivery:
SPIDER mower
Mower ignition key (2×)
Gel battery (12V starting)
Remote control including 2 batteries
Remote control battery charger (12V – 12V)
Operation manual
Radio controller key (2×)
Engine user’s and maintenance manual
Copy of the EC declaration of conformity
Copy of the EC declaration of conformity for
Remote controller NBB
