Operator Manual - Spider ILD02 SG
39 / 51 rev. 01-01-04-2011
11.15 MOWING BLADES
Check the state of cutting blades in regular intervals
The blades:
Must not show signs of damage such as twisted,
bent or deformed parts of blades.
Must be properly attached by the flange in the
middle of blades.
Must be sharp.
The fastening bolts of the flange must not be
damaged.
For proper and reliable functioning the blades are
statically balanced by the manufacturer. This
balance must be preserved during the entire use of
the blade
The blade must be statically balanced after each
sharpening
To tighten the blade, use a torque wrench and a
specified tightening torque of 60 Nm
If the blades are damaged, it is prohibited to:
Straighten them
Heat them
Weld them
Ream them or otherwise change their
construction.
When replacing worn-out parts follow these
rules:
The blade may only be sharpened within the
permitted wear limit. Balancing must be carried
out after sharpening.
The blade cannot be repaired.
When changing the blade, use new fastening
bolts if the current ones show signs of damage.
Only high-tensile steel bolts may be used for this
purpose. No other steel bolts are acceptable.
If the mowing mechanism vibrates when
engaged, do not continue operating the mower,
turn it off and contact your local dealer.
To tighten bolts use torque listed in the chart at
the end of this chapter (see 11.21)
Changing the mowing blades
Raise the mowing device to the transport position.
Stop the engine, switch off the RC and push the
emergency button on the body of the mower.
Disconnect the battery.
Lift one side of the mower until it leans against the
handles on the other side. Always lift the mower on
the exhaust side tilt it against the hydraulic tank
side to prevent oil entering the air cleaner.
Secure the lifted side against falling by supporting
it.
Use gloves when changing the blades.
Loosen the fastening bolts. Remove the bolts and
the washers. Be careful when removing the last
bolt, the blade may fall to the ground.
After the blade is replaced, fasten it by
working in the reversed order.
Always check the bolts when fastening
the blade.
After attaching the blades, check their tightness.
Be very careful when engaging the mowing
mechanism for the first time after replacement.
Check for unknown sounds, vibrations etc.
NOTICE:
Always lift the mower on the
control unit side and tilt against the
fuel tank side to prevent oil
entering the air cleaner. Be aware
of oil spills.
