Operator Manual - Spider ILD02 SG
9 / 51 rev. 01-01-04-2011
3 SAFETY INSTRUCTIONS
This safety symbol indicates important
safety messages in this manual. When
you see this symbol, be alert to the
possibility of injury, carefully read the
message that follows, and inform other operators.
Safety Checks
Do not enter or reach under the machine if it is
lifted and not sufficiently supported. The
machine should be supported on places
marked by the symbol of a lifting jack.
The mower should only by transported in a
container or on a trailer.
Check bolt torques at regular intervals. The first
check should be done after 8 operating hours.
Pay attention to the attachment of the cutting
blade and the proper bolt torque. Use a torque
wrench and a specified torque. See 11.21.
The attaching flange of the blades or the bolts
must not show sign of damage or wear. The
bolts must be complete. The blade must be
undamaged, evenly worn and adequately
sharp.
If you are driving the machine outside the
working area, always turf off the mowing blade
and set the maximum mowing height,
otherwise the blade may get damaged.
Keep the product clean after use. Do not use
gasoline or similar oil products for cleaning.
Do not reach into the space under the mower
with your hands of feet. Do not reach under the
engine cover or into the gear mechanism.
If you are forced to reach under the machine,
wait until all rotating parts stop. Attention, it
takes some time before blade runs down! The
run-down time depends on the state and wear
of the brake/clutch. Have the brake checked at
regular intervals at an authorised servicing
facility.
While operating, wear closed shoes and work
clothing. Do not wear loose clothes that could
get caught by the machine, short trousers or
light shoes.
It is strictly prohibited for the operator to wear
loose clothing.
A local risk assessment should determine the
need for a face shield.
Do not operate the machine after drinking
alcohol or using medication influencing
perception.
Before starting the engine, make sure that the
mower blade is disengaged. If the blade switch
is in the ON position, the machine cannot be
started. When engaging the mower blade, step
aside far enough to be protected against object
accidentally thrown from the mower and to be
able to stop the mower in case of an
emergency. Do not enter the path of the
mower.
While operating the mower make sure that the
mower is clearly visible at all times and within
the range of the remote control unit and that
you can clearly recognize dangerous situations
and react to them properly. Do not abuse the
maximum reach of the remote control.
When using the mower, follow all general work
safety regulations.
Work with the mower may only be started if the
mower is not damaged by previous operation.
Do not change the engine tuning, especially the
engine speed regulator. Do not modify the
exhaust pipe.
Do not use the mower if there is less than 30%
of fuel in the fuel tank.
Do not move the mower by means of towing it
behind another machine.
Operating Environment
The machine should only be used by persons
over 18 years of age, who have been
acquainted with the machine and the user’s
manual .The remote control (further referred to
as ”RC”) is considered a part of the machine
The user’s manual must be stored in a place
permanently accessible to the operator and
must be available to him at all times.
Do not allow children or unauthorised persons
use the product.
Before starting to operate the machine, you
have to be familiar with all the symbols next to
the controls and indicators used on the mower
and the RC.
Pay special attention to the stopping and
shutting-off of the engine and to the emergency
shutting-off of the mower.
Before using the mower on a slope, make sure
you test and practice your mower-control skills
on flat and level ground, which is sufficiently
free and spacious. Master how to control the
movement on a surface, to mow around
bushes, trees and other terrain elements and
obstacles.
When operating the mower on slope, make
sure that the engine revolutions are set to
maximum speed. If you stop the mower on a
slope, position the wheels across the slope.
