Spirax Sarco 1600V - Page 5

(ode
ser.p
bavd
sp.ty
type
5
• Ser
Ser
Instrument identification code when
connected in serial line (if enabled)
[see “hrd.1” in Hrd]
Serial communications
Digital
communication
protocol:
CENCAL, MODBUS
Baudrate
38
39
40
0 ... 9999
SEr.P Digital communication protocol
0 CENCAL GEFRAN
1 MODBUS RTU
bAud Baudrate CENCAL Interface MODBUS Interface
0 1200 CL / 485 / 232 485
1 2400 485 / 232 485
2 4800 485 / 232 485
3 9600 485 / 232 485
4 19200 485 / 232 485
Parity
101
PAr Parity
0 No parity
1 Odd
2 Even
Setpoint type:
LOC/REM,
Select type of remote
setpoint [0...3]
Probe type, signal and scale of main input
tYPE Probe type Scale Scale range max. Scale range max.
(C/F) without decimal point with decimal point
0 J (Fe-CuNi) C 0 / 1000 0.0 / 999.9
1 J (Fe-CuNi) F 32 / 1832 32.0 / 999.9
2 K (NiCr-Ni) C 0 / 1300 0.0 / 999.9
3 K (NiCr-Ni) F 32 / 2372 32.0 / 999.9
4 R (Pt13Rh - Pt) C 0 / 1750 not available
5 R (Pt13Rh - Pt) F 32 / 3182 not available
6 S (Pt10Rh - Pt) C 0 / 1750 not available
7 S (Pt10Rh - Pt) F 32 / 3182 not available
8 T (Cu-CuNi) C -200 / 400 -199.9 / 400.0
9 T (Cu-CuNi) F -328 / 752 -199.9 / 752.0
10 B (Pt30Rh - Pt6Rh) C 44 / 1800 not available
11 B (Pt30Rh - Pt6Rh) F 111 / 3272 not available
12 E (NiCr-CuNi) C -100 / 750 -100.0 / 750.0
13 E (NiCr-CuNi) F -148 / 1382 -148.0 / 999.9
14 N (NiCrSi-NiSi) C 0 / 1300 0.0 / 999.9
15 N (NiCrSi-NiSi) F 32 / 2372 32.0 / 999.9
16 (Ni - Ni18Mo) C 0 / 1100 0.0 / 999.9
17 (Ni - Ni18Mo) F 32 / 2012 32.0 / 999.9
18 L - GOST (NiCr-CuNi) C 0 / 600 0.0 / 600.0
19 L - GOST (NiCr-CuNi) F 32 / 1112 32.0 / 999.9
20 TC C custom scale (*)
21 TC F custom scale (*)
tYPE Probe type Scale Scale range max. Scale range max.
(C/F) without decimal point with decimal point
0 PT100 C -200 / 850 -199.9 / 850.0
1 PT100 F -328 / 1562 -199.9 / 999.9
2 JPT100 (JIS C 1609/81) C -200 / 600 -199.9 / 600.0
3 JPT100 (JIS C 1609/81) F -328 / 1112 -199.9 / 999.9
4 RTD C custom scale (*)
5 RTD F custom scale (*)
(*) Linearisation and scale limit settings (whit or without decimal point)
are selectable from PC via serial line
PROBE: 3 wires RTD (SEnS=1)
PROBE: PTC (SEnS=2) (on request, alternative to 3-wires RTD)
• InP
InP
Input settings
44
45
SP.tY Type of remote Absolute
setpoint Relative
0 analogue (InP.2) absolute
1 analogue (InP.2) relative to
local setpoint
2 digital absolute
(from serial line)
3 digital relative to
(from serial line) local setpoint
SENSORE: TC (SEnS=0)
+4 gradient to setpoint (digit/sec)
tYPE Probe type Scale Scale range max. Scale range max.
(C/F) without decimal point with decimal point
0 PTC 990Ω C -55 ... 120 -55.0 ... 120.0
1 PTC 990Ω F -67 ... 248 -67.0 ... 248.0
2 PTC 990Ω C custom scale (*)
3 PTC 990Ω F custom scale (*)
tYPE Signal type Scale Scale range max.
0 0...50mV linear -1999 / 9999
1 0...50mV custom linearised see table in menu Lin
2 10...50mV linear -1999 / 9999
3 10...50mV custom linearised see table in menu Lin
PROBE: VOLTAGE 50mV (SEnS=3)
tYPE Signal type Scale Scale range max.
0 0...20mA linear -1999 / 9999
1 0...20mA custom linearised see table in menu Lin
2 4...20mA linear -1999 / 9999
3 4...20mA custom linearised see table in menu Lin
PROBE: CURRENT 20mA or TRANSMITTER (SEnS=4)
tYPE Signal type Scale Scale range max.
0 0...10V linear -1999 / 9999
1 0...10V custom linearised see table in menu Lin
2 2...10V linear -1999 / 9999
3 2...10V custom linearised see table in menu Lin
PROBE: VOLTAGE 10V or TRANSMITTER (SEnS=5)
tYPE Signal type Scale Scale range max.
0 Custom 0...10V linear -1999 / 9999
1 Custom 0...10V custom see table
linearised in menu Lin
PROBE: CUSTOM 10V (SEnS=6)
tYPE Signal type Scale Scale range max.
0 Custom linear -1999 / 9999
1 Custom custom see table
linearised in menu Lin
PROBE: CUSTOM 50mV, 20mA (SEnS=7)
