Digital filter on main input
Digital filter on display
process variable:
acts as hysteresis
Decimal point position for
the main input scale,
alarms and
remote setpoint
(*) not available for
TC, RTD and PTC scales
Minimum limit of the main
input scale
Maximum limit of the
main input scale
Offset correction of the
main input
Digital filter on auxiliary
input (if enabled)
[see “hrd.1” in Hrd]
Function of auxiliary
analogue input
(if enabled)
[see “hrd.1” in HrD]
and custom scale
limitation enable
Minimum limit of the
auxiliary input scale
(if enabled)
[see “hrd.1” in Hrd]
Maximum limit of the
auxiliary input scale
(if enabled)
[see “hrd.1” in Hrd]
Offset correction of the
auxiliary input (if enabled)
[see “hrd.1” in Hrd]
Low limit for the local
setpoint and absolute
alarms
High limit for the local
setpoint and absolute
alarms
+ 8 to select custom linearisation
(see table in menu Lin)
46
47
48
49
50
51
52
53
54
55
56
57
58
0.0 ... 20.0 sec
0 ... 9.9
scale points
dP_S Format
0 xxxx
1 xxx.x
2 xx.xx (*)
3 x.xxx (*)
min...max input range
selected in tyPE
min...max input range
selected in tyPE
-999 ... 999
scale points
tYP.2 Auxiliary input function
0 none
1 remote setpoint
2 remote analogue manual
3 analogue reset power
4 current transformer
input for HB
5 Valve position
0.0 ... 20.0 sec
min...max input range
selected in tyP.2
min...max input range
selected in tyP.2
-999 ... 999
scale points
Lo.S ... Hi.S
Lo.S ... Hi.S
• Out
61
Out
Output settings
Select
reference
signal for
alarm 1
AL.1.r, AL.2.r, AL.3.r
Select
reference
signal for
alarm 2
Select
reference
signal for
alarm 3
60
62
AL.x.r Variable to compare Alarm Setpoint
0 PV (process variable) AL
1 InP.2 (auxiliary input) AL
2 SSP (active setpoint) AL (only absolute)
3 PV (process variable) InP.2
(auxiliary input)
+ 4 for relative allarms only, referring to SP1 only
4available if the “multiset” function has been selected)
64
63
Alarm 1
type
Alarm 2
type
Alarm 3
type
+ 8 to disable on power up until the first interception
+ 16 to latch the alarm
65
AL.x.t Direct (high limit) Absolute or Normal
Inverse (low limit) Relative Symmetric
to setpoint (window)
0 direct absolute normal
1 reverse absolute normal
2 direct relative normal
3 reverse relative normal
4 direct absolute symmetric
5 reverse absolute symmetric
6 direct relative symmetric
7 reverse relative symmetric
AL.1.t, AL.2.t, AL.3.t
HB alarm
function
66
Hb_F Function description
0 Relay, logic output: alarm active on load
current level lower than setpoint during the
ON time of the control outptut
1 Relay, logic output: alarm active on load
current level higher than setpoint during
the OFF time of the control output
2 Alarm active if one of the functions 0 and 1
is true (OR logic between 0 and 1) (*)
3 HB alarm for heating analog output
7 HB alarm for cooling analog output
+ 0 associated to output OUT1 (only for Hb_F= 0, 1, 2)
+ 4 associated to output Out2 (only for Hb_F= 0, 1, 2)
+ 8 associated to output Out3 (only for Hb_F= 0, 1, 2)
+ 12 associated to output Out4 (only for Hb_F= 0, 1, 2)
+ 16 inverse HB alarm
(*) the minimum set is fixed at 12% f.s.
