Spirax Sarco 1600V - Page 9

st.00
st.32
xead
pa.01
pa.14
bargled.1
led.2
led.3
LEd.x Function
0 None
1 MAN/AUTO (ON in manual, OFF in auto)
2 LOC/REM (ON in remote, OFF in local)
3 Selftuning active
4 Autotuning active
5 IN1 repetition
6 IN2 repetition
7 Serial communications in operation
8 HOLD inserted
9 Error present (error code <> 0)
10 Softstart in operation
11 SP1 ... SP4 indication - Lo bit
12 SP1 ... SP4 indication - Hi bit
13 Start / Stop Timer
14 Reset Timer
Function of the "MAN": M/A, L/R, ATUN LEDs, IN1, IN2 repetition,
event programmer, serial port enabled, errors present
+ 16 for flashing indication
LEd.1 (MAN), LEd.2 (AUX), LEd.3 (REM)
9
Bargraph
function
bArG
0 Heat
1 Cool
2 Heat + Cool
3 PV
4 Aux. input
(V2 valve position)
5 Setpoint
6 V0 or V1 valve position
7 Time (timer)
8 Deviation (PV - setpoint)
-10% ... +10%
• Lin
Lin
Custom linearisation for main or auxiliary
input (*)
Step 0
Step 32
......
Scale limits
Scale limits
• CuSt
Number of parameters in
the custom menu
[ 0 ... 14 ]
CuSt
Custom “dAtA” menu
Identification code for
parameter 1
Identification code for
parameter 14
......
• U.CAL
U.CAL
User
calibration
X X X X
x
The identification code is specified in this
position, under the parameter name
(*) Not available for:
input correction function enabled (SEnS + 8)
custom TC input (SEnS = 0; tyPE= 20, 21)
custom RTD input (SEnS = 1; tyPE= 4, 5)
custom PTC input (SEnS = 2; tyPE= 2, 3)
U.CAL Function
1 Analogue output 1
2 Analogue output 2
3 Input 1 - custom probe 10V
4 Input 1 - custom probe 50mV
5 Input 2 - potentiometer
