sens
sns.2
al.nr
bvtt
bvt.2
d.1.f.1
d.1.f.2
disp
hrd.1
hrd.2
hrd.3
(trl
s.s.t.
r.t.
• Hrd
Hrd
Hardware configuration
Installation of
auxiliary input,
digital input, serial
interface, timer
function, multiset
function
Installation of
relay, logic
outputs
MAIN, AL1,
AL2, AL3,
and analogue
outputs
W1, W2
+ 16 to enable analogue output W1
+ 32 to enable analogue output W2
+ 64 to invert the state of the LEDs with respect to the state of the output
+ 8 to enable HB alarm
+ 16 to enable LBA alarm
d.i.F.1, d.i.F.2
Function of digital
input 1 (IN1)
+ 16 for inverse logic input
+ 32 to force “0” logic state (OFF)
+ 48 to force “1” logic state (ON)
Function of digital
input 2 (IN2)
hrd.1 Auxiliary Logic Logic Serial
analogue input 1 input 2 interface
input (IN1) (IN2)
0
1 x
2 x
3 x x
4 x
5 x x
6 x x
7 x x x
8 x
9 x x
10 x x
11 x x x
12 x x
13 x x x
14 x x x
15 x x x x
hrd.2 MAIN AL1 AL2 AL3
output output output output
(relay, logic) (relay, logic) (relay, logic) (relay, logic)
0
1 x
2 x
3 x x
4 x
5 x x
6 x x
7 x x x
8 x
9 x x
10 x x
11 x x x
12 x x
13 x x x
14 x x x
15 x x x x
SnS.2 Signal
0 0 ... 1V
1 0.2 ... 1V
2 0 ... 10V
3 2 ... 10V
4 0 ... 20mA
5 4 ... 20mA
6 Potentiometer
7 CT 50mA
~
AL.nr Alarm 1 Alarm 2 Alarm 3
0 disabled disabled disabled
1 enabled disabled disabled
2 disabled enabled disabled
3 enabled enabled disabled
4 disabled disabled enabled
5 enabled disabled enabled
6 disabled enabled enabled
7 enabled enabled enabled
0 none (key disabled)
1 MAN / AUTO selection
2 LOC / REM
3 HOLD
4 Start / Stop timer
5 Reset timer
6 Software power on/off
7 Reset alarm memory
8 SP1 ... SP2 selection (2SP)
SP1 ... SP4 selection - bit Lo
9 SP1 ... SP4 selection - bit Hi
Selection of the
input type for the
auxiliary input
Select the number
of enabled alarms
+16 to enable timer function
+ 32 to enable multiset function (2 setpoints)
+ 64 to enable multiset function (4 setpoints)
Timer Start / Stop
0 from digital input
1 from AL1 ON
2 from AL2 ON
3 from AL3 ON
4 from ALHb ON
5 from serial line (address 0049H, bit 0
6 from serial line (address 0049H, bit 1)
7 from keys
Timer Reset
(0 ... 15)
+ 8 to enable the main input curve 4 point correction
(alternative to custom linearisation).
See the “Input Reading Correction Function”
section.
+16 to disabled the averaging filter on input sampled
value (available from software release 3.05)
+8 to disabled the averaging filter on input sampled
value (available from software release 3.05)
SEnS Probe type for main input
0 Thermocouple (TC)
1 Resistance Thermometer (RTD)
2 Thermistor (PTC)
3 Voltage 0...50mV / 10...50mV
4 Current 0...20mA / 4...20mA
5 Voltage 0...10V / 2...10V
6 Custom 10V
7 Custom 50mV
Selection of the
input type for the
main input
8
Control type
[0...11]
43
CtrL Control type
0 P heat
1 P cool
2 P heat / cool
3 PI heat
4 PI cool
5 PI heat / cool
6 PID heat
7 PID cool
8 PID heat / cool
9 ON-OFF heat
10 ON-OFF cool
11 ON-OFF heat / cool
12 PID heat + ON-OFF cool
13 ON-OFF heat + PID coll
14 PID heat + cool with relative
gain (see C.MEd parameter)
0 none (key disabled)
1 MAN / AUTO selection
2 LOC / REM
3 HOLD
4 Start / Stop selftuning
5 Start / Stop autotuning
6 Set/Reset outputs OUT 1 ... OUT 4
7 Reset alarm memory
8 SP1 / SP2 selection
9 Integral action reset
10 START / STOP
timer (if enable in S.S.t.)
11 RESET timer
(if enable in _ _ r.t.)
+16 Autoreset enabled (STOP = Program
RESET)
(for the _S.S.t. parameter)
+8 inverse action
+ 16 disable the function display in the
configuration menu
Selection of derivate action sampling time:
+0 sample 1 sec.
+16 sample 2 sec.
+32 sample 8 sec.
+64 sample 240 msec.
“*” Key
and bargraph
installation
hrd.3 “*” Key Bargraph
0
1 x
2 x
3 x x
b u t t , b u t .2
Function of M/A
key
Function of “*”
key
Defining SV
display function
diSP Lower display (SP) function
(*) 0 SSP - setpoint enabled
(*) 1 InP.2 - auxiliary input
(*) 2 Control output
(*) 3 Deviation (SSP - PV)
8 Display of current time on
PV display and tS time on
SV display
(*) + 4 Timer (when active)
Note: scale selected under “tYPE” in “InP”.
In case of ON/OFF control the LBA alarm is
not enabled
-
--
