58
10.6 Input technical data
Level voltage
Minimum voltage 0 Vdc or 1 V (with OUTRANGE function selected)
Maximum voltage 6 Vdc (absolute maximum = 7 Vdc)
Input impedance 28 kΩ
Accuracy 5% FSD over operating range
Repeatability 2.5% FSD over operating range
Resolution 14 bit (0.15 mV approx)
Sample time 260 Hz
4-20 mA(s)
Minimum current 0 mA
Maximum current 22 mA
Input impedance 110 Ω
Accuracy 5% FSD over operating range
Repeatability 2.5% FSD over operating range
Resolution 14 bit (1 µA approximately)
Sample time 260 Hz
Level 'out of range' alarm - voltage
Minimum alarm level < 0.2 Vdc
Minimum recovery level > 1 Vdc
Maximum alarm level > 6.5 Vdc
Maximum recovery level < 6 Vdc
Level 'out of range' alarm - current
Minimum alarm level < 2.5 mA
Minimum recovery level > 4 mA
Maximum alarm level > 21 mA
Maximum recovery level < 20 mA
