59
10.7 Output technical data
24 Vdc supply
Maximum voltage 24 Vdc (nominal)
Maximum current 25 mA
Ripple voltage 10 mV at 264V, full load
4-20 mA(s)
Minimum current 0 mA
Maximum current 20 mA
Open circuit voltage
(maximum)
19 Vdc
Resolution 1% FSD
Maximum output load 500 ohm
Isolation 100 V
Output rate 10/second
Relay(s)
Contacts 2 x single pole changeover relays (SPCO)
Voltage Ratings (max) 250 Vac
Resistive load 3 amp @ 250 Vac
Inductive load 1 amp @ 250 Vac
ac motor load
¼ HP (2.9 amp) @ 250 Vac
1
/
10
HP (3 amp) @ 120 Vac
Pilot duty load C 300 (2.5 amp) - control circuit/coils
Electrical life (operations) 3 x 10
5
or greater depending on load
Mechanical life (operations) 30 x 10
6
RS485
Physical layer RS485 4-wire full or 2-wire half duplex
Protocol Modbus RTU format
Isolation 60 Vac/dc
Receiver unit load
(256 devices - maximum) - Based on all 256 devices
having a load input.
Output rate Up to 10 frames / second
Infrared
Physical layer IrDA
Baud 38400
Range 10 cm
Working angle 15°
Eye safety information
Exempt from EN 60825-12: 2007 safety of laser products.
Does not exceed the accesible limits (AEL) of class 1.
