60
10.8 Programming parameters
The default settings in this table can be used as a ‘quick start’ guide. See Section 6.
10.8.1 MODE MENU
Proportional control allows the valve to be manually opened, closed or stopped
Ranges OPEN, CLOSED or STOP
Default STOP
In ON / OFF control
Allows the pump to be switched on or off manually
Ranges PUMP ON or PUMP OFF
Default PUMP OFF
10.8.2 INPUT MENU
LEVEL - SENSOR (Input signal/type)
Ranges 1 - 6 V or 4 - 20 mA
Default 1 - 6 V
LEVEL - OUTRANGE
Ranges ON or OFF
Default OFF
LEVEL - FILTER
Ranges 2, 8 or 16
Default 2
Units Seconds
LEVEL - INTEGRAL (Integral or reset time)
Ranges 5 - 300
Default OFF but 120 if ON is selected
Resolution (steps) 1
Units Seconds
