Page #65 background image
IM-P402-128 EMM Issue 7
65
INPUT - FLOW (Signal from water meter)
Ranges 0.00 - 22.73
Resolution (steps) 0.01
Units dc milliamps
INPUT - STEAM (Signal from steam meter)
Ranges 0.00 - 22.73
Resolution (steps) 0.01
Units dc milliamps
OUTPUT - RETRANS (Sets the output between 4-20 mA manually)
Ranges 4 - 20 mA
Default 20.00
Resolution (steps) 0.01
Units mA
OUTPUT - POSITION (Sets the output between 4-20 mA manually)
Ranges 4 - 20 mA
Default 20.00
Resolution (steps) 0.01
Units mA
OUTPUT - VALVE - +VALVE or -VALVE or PUMP (Manual valve control)
Ranges ON or OFF
Default ON
Press the
OK
button to activate the relay - Automatic control of relays is selected by
selecting cancel or after 5 minutes has elapses.
OUTPUT - ALARM (Energises or de-energises the alarm relay manually)
Ranges ON or OFF
Default ON
Press the
OK
button to activate the relay - Automatic control of relays is selected by
selecting cancel or after 5 minutes has elapses.
SET PASS MENU (Set pass code)
Ranges 0000 - 9999
Default See Section 2
Resolution 1
TREND MENU (Sets time base of trend graph)
Ranges MINS, HRS, DAYS
Default MINS
