SP400 Electropneumatic Smart Positioner
Display = 100%
Display = 0%
Display = 100%
Display = 0%
Fig. 35
2-port valve normally open - TRAVL setting = 100% to 0%
Fig. 36
2-port valve normally closed - TRAVL setting = 100% to 0%
