SP7-20 Smart Positioner
5.3.2 SP7-21/22 Parameter overview
Parameter Display Function Possible
parameter
setting
Unit Factory
setting
P6.4 ADJ_MODE Auto adjust
mode
Dead angle 0 % FULL, STROKE,
CTRL_PAR,
ZERO_POS, LOCKED
--- FULL
P6.5 EXIT Return Return to
operating level
Function --- NV_SAVE
P7._ CTRL_PAR
P7.0 KP UP KP value, up KP value (up) 0.1 to 120.0 --- 1.0
P7.1 KP DN KP value,
down
KP value (down) 0.1 to 120.0 --- 1.0
P7.2 TV UP TV value, up TV value (up) 10 to 450 msec 100
P7.3 TV DN TV value,
down
TV value (down) 10 to 450 msec 100
P7.4 GOPULSUP Go pulse up --- 0 to 200 msec 0
P7.5 GOPULSDOWN Go pulse,
down
0 to 200 msec 0
P7.6 Y-OFSUP Y offset up Y offset up Y-Min to 100.0 % 40.0
P7.7 Y-OFSDN Y offset down Y offset down Y-Min to 100.0 % 40.0
P7.8 --- ---
P7.9 TOL_BAND tolerance
band (zone)
Tolerance band
(zone)
0.3 to 10.0 % 0.8
P7.10 TEST Test Test Function --- INACTIVE
P7.11 EXIT Return Return to
operating level
Function --- NV_SAVE
P8._, P9._,
P10._
P11._ FS/IP
P11.0 FAIL_POS Safe postiton Safe position ACTIVE, INACTIVE --- INACTIVE
P11.1 FACT_SET Factory
setting
Factory setting Function --- ---
P11.2 IP-TYP I/P module
type
Type of I/P
module
NO_ F_POS,F_
SAFE_1,F_SAFE_2,
F_FREEZE1, F_
FREEZE2
--- NO_ F_POS
P11.3 EXIT Return Return to
operating level
Function --- ---
*Activation by Spirax Sarco Service only
Note: For detailed information on the parameterization of the device, consult the associated configuration
and parameterization instructions.
