Spirax Sarco SX80 - Quick Code Functions

IM-P323-32
CTLS Issue 5
20
SX80 and SX90 Quickstart Guide
2.6 Quick code functions
See Section 2.4 for details on the Quick Code.
2.6.1 Quick code - Character 1
Function – Input type and range
P Pt100 RTD 99.9ºC to 300.0ºC
0 4 - 20 mA 0 to 1.6 bar
1 4 - 20 mA 0 to 2.5 bar
2 4 - 20 mA 0 to 4.0 bar
3 4 - 20 mA 0 to 6.0 bar
4 4 - 20 mA 0 to 10 bar
5 4 - 20 mA 0 to 16 bar
6 4 - 20 mA 0 to 25 bar
7 4 - 20 mA 0 to 40 bar
8 4 - 20 mA -50 to +500 °C
9 4 - 20 mA 0 to +100 °C
K K t/c -200ºC to +1372ºC
