IM-P323-32
CTLS Issue 5
44
SX80 and SX90 Quickstart Guide
4.3 Level 2 parameters
Press the button to step through a list of parameters. After 5 seconds
the parameter mnemonic is followed by a scrolling description.
Press the or buttons to adjust the value/range of the parameter.
Mnemonic Scrolling Text Range
WRK.OP WORKING OUTPUT
Active output value. Shown when the
controller is in AUTO or OFF mode. Read
only.
WRK.SP
WORKING
SETPOINT
Active setpoint value (SP1, SP2, SP3 or REM.
SP). Shown when the controller is in MAN or
OFF mode. Read only.
UNITS DISPLAY UNITS ºC, ºF, ºk, non, perc (%)
SP.HI SETPOINT HIGH
High and low setpoint limit applied to SP1,
SP2, SP3 and Remote Setpoint REM.SP.
SP. LO SETPOINT LOW
SP1/2/3 SETPOINT 1, 2 or 3
Setpoint 1, 2 or 3 adjust. Alterable between
SP.HI a nd S P. LO.
SP.RRT
SETPOINT RISING
RATE LIMIT
Sets increasing rate of
change of SP.
Alterable: OFF to 3000
units/min
When set to a
value, 'RUN'
illuminates
when the
setpoint is
changed.
SP.FR T
SETPOINT FALLING
RATE LIMIT
Sets decreasing rate of
change of SP.
Alterable: OFF to 3000
units/min
To Next Page
