SX80 and SX90 Quickstart Guide
Mnemonic Scrolling Text Range
HOLD/B HOLDBACK
SX09 only. Stops the setpoint ramp if
deviation between SP and PV > the set value.
Range OFF or 1 to 9999.
TM.CFG
TIMER
CONFIGURATION
None = no timer configured SF.St = A soft
start timer starts automatically on power up.
It applies a power limit (SS.PWR) until the PV
reaches a threshold value or the timer times
out (DWELL). The threshold value = WKG.SP
– SS.SP. It does not operate with boundless
valve position.
Further parameters are shown if soft start is configured
(See Note 1).
