IM-P323-32
CTLS Issue 5
46
SX80 and SX90 Quickstart Guide
Mnemonic Scrolling Text Range
A1/2.x x
ALARM 1/2
SETPOINT (if
configured)
xx = HI (high), LO (low), D.HI (deviation low),
BND (deviation band). Alterable over the
controller range.
MTR.T
MOTOR TRAVEL
TIME
Set this to the time taken for the motor to
travel from fully closed to fully open. 0.0 to
999.9 seconds
A.TUNE
AUTO-TUNE
ENABLE
Automatically sets the control parameters to
match the process characteristics. Set to On
to start the process.
PB
PROPORTIONAL
BAND
1 to 9999 display units Default: 20.
TI INTEGRAL TIME
1 to 9999 seconds. OFF can be set if control
type = PID.
Default: 360.
TD DERIVATIVE TIME OFF, 1 to 9999 seconds. Default: 60 for PID.
MR MANUAL RESET
Not for VP. Otherwise range –100.0 to
100.0%
R2G
RELATIVE COOL
GAIN
Adjusts the cooling proportional band
relative to the heating proportional band.
Heat/cool only. Range 0.1 to 10.0.
Default 1.0.
D.BAND
CHANNEL 2
DEADBAND
Sets a zone between heating and cooling
outputs when neither output is on. Quick
Code Function 2 = A only. Range OFF or 0.1
to 100.0% of the cooling proportional band.
These parameters are further described in the Engineering Manual.
Note 1: TM.RES, TIMER RESOLUTION; SS.PWR,SOFT START POWER
LIMIT; SS.SP, SOFT START SETPOINT; DWELL, SET TIME DURATION;
T.REM, TIME REMAINING.
