IM-P736-02 EMM Issue 3
5
VLM30 In-Line Vortex Flowmeter
3. Installation
19
3.1 Installation Conditions 20
3.2 Inlet and Outlet Recommendations 21
3.3 Installation at high measuring medium temperatures 22
3.4 Installation for external pressure and temperature measurement
23
3.5 Installation of setting equipment
3.6 Sensor Insulation 24
3.7 Ambient Conditions 25
3.8 Material Load 26
3.9 Installing the sensor 30
3.10 Centering the wafer type design 31
3.11 Adjusting the transmitter position 32
3.12 Rotating the LCD indicator 33
3.13 Opening and closing the housing 34
3.14 Signal Cables
35
3.15 Installing the connection cables
3.16 Cable glands
36
3.17 Grounding
3.18 Devices with HART
®
communication 37
3.19 Devices with Modbus
®
communication 44
3.20 Cable specication
47
3.21 Connection to remote mount design
4. Commissioning
51
4.1 Safety instructions
4.2 General
4.3 Digital output 52
4.4 Checks prior to commissioning 53
4.5 Power Supply Power-Up
544.6 Checks after switching on the power supply
4.7 Checking and conguring the basic settings
4.8 Parameterisation via the menu function Easy Setup 55
4.9 Devices with HART
®
and Modbus
®
communication 62
