IM-P736-02 EMM Issue 3
50
VLM30 In-Line Vortex Flowmeter
Note: The shielding of the signal cable also serves as a functional ground and must be connected to the
sensor and to the transmitter on both sides.
-
Use the signal cable connected to the transmitter to make the electrical connection between the measuring
sensor and the transmitter.
-
Unscrew the cover of the terminal boxes on the transmitter and the measuring sensor.
-
Produce the signal cable in accordance with the specification (see Figure 31).
-
Insert the cable through the cable gland into the terminal box.
-
Tighten the cable gland.
-
Connect the wires to the corresponding terminals (see Figure 32).
-
Connect the shield of the signal cable to the forked cable lug to the ground terminal.
-
Screw on the cover of the terminal compartment on the transmitter and the measuring sensor and tighten
by hand. Make sure the gaskets for the cover are seated properly.
