L. Service door (side panel)
M. Pre-ground co ee chute
N. Drip tray
O. Identi cation plate
(inside, remove
drip tray)
P. Water indicator level
Q. Co ee grounds container
R. Power cord storage compartment
S. Bean container (inside)
A. Display
B. Strength/volume selector
C. Steam/hot water control
D. One cup/two cup co ee button
E. Steam/rinsing button
F. Height-adjustable co ee spout
G. Water tank cover
H. Water tank
I. On/O switch
J. Cup holding plate
K. Steam/hot water spout/frothing
device
FAMILIARISING YOURSELF WITH YOUR TS4
E
S
F
H
FIGURE 1
I
J
K
L
M
N
O
P
R
E
Q
A
B
G
D
C
