APV_CU4 AS-i_UK-5_072018.indd
UK
Control Unit
CU4 AS-interface
Instruction manual: UK - rev. 5
APV
17
4. MechanicsandPneumatics
4.5. TechnicalData/Standards
Material: PA6.6
Ambienttemperature: -20°C to +70°C
EU: EMC2014/30/EU(89/336/EEC)
Standards and
environmentalaudits: Protection class IP 67 EN60529/
complies with NEMA 6
EMC interference resistance
EN61000-6-2
EMC emitted interference
EN61000-6-4
Vibration/oscillation EN60068-2-6
Safety of machinery
DIN EN ISO 13849-1
Airconnection: 6 mm / ¼" OD
Pressurerange: 6–8 bar
Compressedairquality: Quality class acc. to
DIN ISO 8573-1
- Contentofsolidparticles: Quality class 3,
max. size of solid particles per m³
10000of0,5μm<d<1,0μm
500of1,0μm<d<5,0μm
- Contentofwater: quality class 3,
max. dew point temperature -20 °C
For installations at lower
temperatures or at hight altitude,
additional measures must be
considered to adopt the pressure
dew point accordingly.
- Contentofoil: quality class 1,
max. 0,01 mg/m³
TheoilappliedmustbecompatiblewithPolyurethane
elastomer materials.
