APV_CU4 AS-i_UK-5_072018.indd
UK
Control Unit
CU4 AS-interface
Instruction manual: UK - rev. 5
APV
23
6. Electronic module
6.4. TechnicalData
AS-interfaceprofile: S-7.A.*.E(S-7.F.F.Fasoption)
Extendedaddressrange: is supported
Serialcommunicationmode: no
Inversepolarityprotection: exists
Indication"Power": LED3(green)
Indication"Fault": LED3(red)
AS-interfacevoltagerange: 26,5…31,6 V
Max.powerinput: <=150mA
Inputdelaytime: <1s
AS-interfacespecification: V3.0
Supplyofsolenoidvalves: PWM signal from
electronic module
Short-circuitprotection: yes
Excessvoltageprotection: 100 mA
Inductionprotection: ja
Statusindicationofoutputs: LED on board
Responsetimeofwatchdog: ---(watchdognotactivated)
Short-circuitorexcessvoltageofactuatorsupplyorcable
breakatvalvesissignalledtothemasterviatheperipheral
failurebit(profileS-7.A.*.Eonly).
SimultaneouslyLED3flashesaccordingtoAS-interface
specificationalternatelyred/green.
Supplyofsensors: 5VDC(±5%)
Note: The sensor inputs and the
peripheral supply must not be
connected with installation-
GND.
Connecting terminals: conductor cross section
0,5-1,5 mm² (with conductor
sleeve)complyingwithAWG
20-16
