SRAM G2 ULTIMATE - Page 13

13Caliper Piston Removal
Squeeze the brake lever to advance the pistons until they contact the
pad spacer.
Use a T25 TORX wrench to remove the banjo bolt.
Remove the pad spacer.
Remove the pad retention bolt.
4
5
2.5 mm 20 mm or 15 mm Thru Axle
6
2.5 mm QR
