14Caliper Piston Removal
Remove each caliper body bolt.
Separate the caliper body halves.
Remove both of the caliper o-rings from the inboard side of the caliper.
Remove the pistons from each caliper body half.
NOTICE
If it is not possible to remove the pistions by hand, soft-jawed pliers
may be used to carefully remove the pistons.
7
T25 Rubber-tipped blow gun chuck nozzle 22 mm
8
9
10

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the SRAM G2 ULTIMATE and is the answer not in the manual?

SRAM G2 ULTIMATE Specifications

General IconGeneral
TypeHydraulic Disc Brake
Caliper Design4-piston
AdjustmentTool-free Reach Adjust, Contact Point Adjustment
FluidDOT 5.1
Caliper MaterialForged Aluminum
Rotor Compatibility200mm, 180mm, 160mm
Intended UseTrail
Brake PadsOrganic
