SRAM G2 ULTIMATE - Page 32

32Piston Assembly Installation
Black SwingLink only: Apply a small amount of Loctite Threadlocker
Blue 242 onto the pinch bolt.
Black SwingLink only: Use a T8 TORX wrench to thread the SwingLink
pinch bolt into the lever body. Use a torque wrench and a T8 TORX bit
socket to torque the bolt to 1.2 N·m (10.5 in-lb).
10
Loctite Threadlocker Blue 242 20 mm or 15 mm Thru Axle
T8 QR
11
T8 1.2 N•m (10.5 in-lb) 22 mm
