SRAM HydroR - Page 14

14
Caliper Piston Installation
Tighten the banjo bolt.
Spray isopropyl alcohol on the caliper body and clean it with a rag.
Insert the bleed block into the caliper. Install the pad retention bolt.
Cut the hose to install a new barb and compression fitting.
NOTICE
You must install a new hose barb and compression fitting before
reconnecting the brake lever to the hose.
7
9.8-11.8 N·m (86-104 in-lb) 8 mm
9.8-11.8 N·m (86-104 in-lb) T25
Post Mount
Flat Mount
8
9
2.5 mm Bleed block
10
SRAM Hydraulic Hose Cutter
2.7 - 3.2 N·m (24-28 in-lbs) 22 mm
