Srne ASF4880SH3 - Cable & circuit breaker requirement

9
File version: V1.0
4.2 Cable & circuit breaker requirement
• PV input
Models
Cable Diameter
Max. PV Input
Current
Circuit
Breaker Spec
ASF4880SH3
5mm²/ 10 AWG
22A
2P-25A
ASF48100SH3
5mm²/ 10 AWG
22A
2P-25A
ASF48120SH3
5mm²/ 10 AWG
22A
2P-25A
• AC input
• Battery
• AC output
Models
Output Mode
Max. Current
Cable Diameter
Circuit
Breaker Spec
ASF4880SH3
Three-phase
25.5A
6mm²/8 AWG(L1/L2/L3/N)
4P-40A
ASF48100SH3
Three-phase
31.9A
7mm²/8 AWG(L1/L2/L3/N)
4P-50A
ASF48120SH3
Three-phase
38.2A
9mm²/6 AWG(L1/L2/L3/N)
4P-63A
Models
Cable Diameter
Max. Current
Circuit Breaker Spec
ASF4880SH3
34mm²/ 2 AWG
180A
2P-200A
ASF48100SH3
42mm²/ 1 AWG
220A
2P-250A
ASF48120SH3
50mm²/ 1 AWG
260A
2P-300A
Models
Output Mode
Max. Current
Cable Diameter
Circuit
Breaker Spec
ASF4880SH3
Three-phase
12.8A
3mm²/12 AWG(L1/L2/L3/N)
4P-20A
ASF48100SH3
Three-phase
16A
4mm²/10 AWG(L1/L2/L3/N)
4P-25A
ASF48120SH3
Three-phase
19.2A
5mm²/10 AWG(L1/L2/L3/N)
4P-32A
