Srne ASF4880SH3 - Datasheet

40
File version: V1.0
9. Datasheet
MODEL
ASF4880SH3
ASF48100SH3
ASF48120SH3
Can Be
Set
INVERTER OUTPUT
Rated Output Power
8,000W
10,000W
12000W
Max. Peak Power
16,000W
20,000W
24000W
Rated Output Voltage
230/400Vac (three-phase)
√
Capacity of Motor Load
5HP
6HP
6HP
Rated Frequency
50/60Hz
√
Output Waveform
pure sine wave
Switching Time
10ms（typical）
Number of parallel
/
Overload Protection
After triggering the overload protection, the inverter will resume
output after 3 minutes, 5 consecutive overloads will shut down
the output until the inverter is restarted.
(102%<load<110%) ±10%: error, output shut down after 5
minutes.
(110%<load<125%) ±10%: error, output shut down after 10s.
(>125% load ±10%): error, output shut down after 5s.
BATTERY
Battery Types
Li-ion / Lead-Acid / User Defined
√
Rated Battery Voltage
48Vdc
Voltage Range
40-60Vdc
√
Max. PV Charging Current
180A
220A
260A
√
Max. Utility / Generator Charging
Current
100A
120A
120A
√
Max. Hybrid Charging Current
180A
220A
260A
√
PV INPUT
No. of MPPT
2
Max. Input Power
6000W/6000W
7500W/7500W
9000W/9000W
Max. Input Current
22/22A
Max. Open-circuit Voltage
800Vdc/800Vdc
MPPT Operating Voltage Range
200-650Vdc/200-650Vdc
UTILITY / GENERATOR INPUT
Input Voltage Range
phase voltage 170~280V, line voltage 305~485V
Input Frequency Range
50 / 60Hz
Bypass Overload Current
63A
EFFICIENCY
MPPT Tracking Efficiency
99.9%
Max. Battery Inverter Efficiency
≥92%
European Efficiency
97.2%
97.5%
97.5%
