File version: V1.0
7
 The user can change the output phase mode and output voltage through the setup menu,
please read chapter 5.2 for details.
 The output voltage corresponds to item [38] of the parameter setting, and the output
phase voltage can be set within the range of 200V to 240V.
4. Connection
4.1 Three-phase mode
Items
Description
Applicable models
ASF series SH3 model
AC output phase voltage (L-N)
200~240Vac, 230Vac default
○
!
NOTICE
