2 Specifications
The STDES-50W2CWBC specifications can be summarized as follows (refer to the figure below for the related
blocks):
• the boost DC-DC supports 60 W (20 V/3 A) input and 30 V+ output
• the full bridge converter supports an AC voltage ≤ ±100 V
• the coil switcher alternatively switches the two LC tanks for coils alternatively into high voltage
• the STLINK-V3MINI interface with SWD for firmware debug and UART for demo GUI
• the I²C interface supports external daughter boards through I²C (for example, STSAFE-A110 for
authentication)
Figure 3. STDES-50W2CWBC main blocks
