7 Conclusions
The test results show the STDES-50W2CWBC reference design can automatically detect and charge the PX by
either of the two coils.
• The Rx output could be from 5 V to 20 V by the ST Super Charge proprietary protocol (STSC).
• The ASK demodulation works well.
• The Q-factor estimation by either of the two coils is close to the LCR meter.
The STDES-50W2CWBC reference design achieved the expected performance.
