Item Q.ty Ref. Part/value Description Manufacturer Order code

60 2 U201-202 STG719STR, SOT23-6L

Low voltage 4 ohm SPDT

switch

ST STG719STR

61 1 U200

STWBC2-HP, VFQFPN

8X8X1.0 68L PITCH 0.4

ROUT A

Digital controller for

wireless battery charger

transmitters

ST STWBC2-HP

62 2

D203

D209

0603 Green LEDs

Wurth

Elektronik

150060VS75000

63 1 D202 0603 Red LEDs

Wurth

Elektronik

150060RS75000

64 2 R235-236

100 R, 0402, 1/16 W, ±5 %,

SMD

Resistors

Yageo or

generic

RC0402JR-07100RL

65 1 C308 47 µF, D6.3

Aluminum electrolytic

capacitor

Panasonic EEEFTH470XAP

66 1 C104

33 nF, 0603, 50 V, ±10 %,

X7R, SMD

Capacitor

Kemet or

generic

C0603C333K5RACTU

TN1399

Bill of materials

TN1399 - Rev 1

page 19/26
