Item Q.ty Ref. Part/value Description Manufacturer Order code
37 1 L200
10 µH, L2.5_W2.0_H1.2, 1.3
A, DCR max 0.540 ohm
ISAT TDK VLS252012HBX-100M-1
38 1 L400
1 µH, IND_L6.8_W6.8, 4.6 A,
RDC = 14 mohm max.
ISAT
Wurth
Elektronik
744062001
39 1 L300
3.3 µH, L9.2_W8.5, 8.25 A,
±20 %, 0.0149 ohm
Power inductor
Wurth
Elektronik
74437358033
40 2 Q411-412 BC856B, SOT323, 80 V PNP ONSEMI BC856BMTF
41 3
Q405
Q410
Q413
NPN, SOT323, 50 V, 100 m
A, 205 mW RB = RC = 10 K
Transistors NXP PDTC114EU,135
42 1 Q100 N-MOS, SOT23, 30 V, 0.56 A Small signal MOSFET ONSEMI NTR4003NT1G
43 1 D400 10 V, SOD323, 0.2 W Voltage regulator
NXP or
generic
BZX384-C10,115
44 1 Q404
P-MOS, POWERDI3333-8,
30 V, 11.5 A
P-MOS
Diodes
Incorporated
DMP3017SFGQ-7
45 2 D401-402
1N4148WS-7-F, SOD323, 75
V, 150 m A
General purpose diodes
Diodes
Incorporated
1N4148WS-7-F
46 2 Q201-202 N-MOS, SOT23
Enhancement mode field
effect N-MOS
ONSEMI 2N7002
47 2
Q200
Q203
N-MOS, SOT723-3, 20 V,
0.89 A
Small signal MOSFETs ONSEMI NTK3134NT1G
48 1 Y200
16MHZ-10PPM-8PF,
L2.0_W1.6
SMD crystal NDK
NX2016SA 16MHz
EXS00A-CS06655
49 1 J100
632723300011,
CON_USB_C_632723300011
USB TYPE
C_632723300011
Wurth
Elektronik
632723300011
50 1 J101
FTSH-107-01-L-DV-K-A,
CON_FTSH-107-01-L-DV-K-
A
SMD_HEADER_2x7_P1.27 Samtec FTSH-107-01-L-DV-K-A
51 1 J201 4PIN, 1X4, 2.54 mm Connector Any -
52 1 D100 ESDA25P35-1U1M, QFN-2L
High-power transient
voltage suppressor
ST ESDA25P35-1U1M
53 1 D102 ECMF02-2AMX6, QFN-6L
Common-mode filter and
ESD protection for USB 2.0
and MIPI/MDDI interfaces
ST ECMF02-2AMX6
54 1 D103 ESDALC6V1M3, SOT883
Dual low capacitance
Transil array for ESD
protection
ST ESDALC6V1M3
55 1 D104 BAT30KFILM, SOD-523
30 V, 300 mA SMD general
purpose signal Schottky
diode
ST BAT30KFILM
56 5 D204-208 BAT54KFILM, SOD-523
40 V, 300 mA general
purpose signal Schottky
diodes
ST BAT54KFILM
57 2 D200-201
RB541VM-40, SOD-323, 40
V, 200 m A,
SMT Schottky diodes Rohm RB541VM-40TE-17
58 10
Q300-301
Q400-403
Q406-409
STL20N6F7, PowerFLAT
3.3x3.3
N-channel 60 V, 0.0046
Ohm typ., 20 A STripFET
F7 Power MOSFETs in
a PowerFLAT 3.3x3.3
package
ST STL20N6F7
59 1 U203 LMV321ILT, SOT23-5L
Low power rail-to-rail input/
output op-amp
ST LMV321ILT
TN1399
Bill of materials
TN1399 - Rev 1
page 18/26
