ST STDES-50W2CWBC - Bill of Materials

6 Bill of materials
Item Q.ty Ref. Part/value Description Manufacturer Order code
1 9
C207
C215
C217-218
C223-224
C226
C236-237
100 nF, 0402, 25 V, ±10 %,
X7R. SMD
Capacitors
Kemet or
generic
C0402C104K3RACTU
2 8
C214
C216
C225
C227
C314-315
C418
C425
10 nF, 0402, 50 V, ±10 %,
X7R, SMD
Capacitors
Kemet or
generic
C0402C103K5RACTU
3 6
C208
C240
C310
C313
C402
C423
1 nF, 0402, 50 V, ±5 %, C0G,
SMD
Capacitors
Kemet or
generic
C0402C102J5GACTU
4 2
C220
C230
1 nF, 0402, 100 V, ±10 %,
X7R
Capacitors
Kemet or
generic
GRM155R72A102KA01D
5 1 C238
1 µF, 0402, 6.3 V, ±10 %,
X7R
Capacitor
Kemet or
generic
C0402C105K3RACTU
6 2 C228-229
33 PF, 0402, 50 V, ±5 %,
C0G, SMD
Capacitors
Kemet or
generic
C0402C330J5GACTU
7 2
C201
C235
4.7 µF, 0402, 6.3 V, ±20 %,
X5R, SMD
Capacitors
Murata or
generic
GRM155R60J475ME47
8 1 C202
470 nF, 0402, 35 V, ±10 %,
X5R, SMD
Capacitor
Kemet or
generic
C1005X5R1V474M050BC
9 2 C221-222
8.2 PF, 0402, 50 V, ±5 %,
C0G, SMD
Capacitors
Kemet or
generic
C0402C829J5GACTU
10 10
C101-102
C304-307
C419-422
10 µF, 1210, 50 V, ±10 %,
X7S. SMD
Capacitors Murata GCM32EC71H106KA03L
11 4
C407-408
C410
C412
100 nF, 1812, 100 V, ±5 %,
G0G, SMD
Capacitors TDK C4532C0G2A104J320KA
12 2
C409
C415
47 nF, 1812, 100 V, ±5 %,
G0G, SMD
Capacitors TDK C4532C0G2A473J200KA
13 12
C100
C203
C210
C241-243
C302
C309
C400
C431-433
100 nF, 0603, 50 V, ±10 %,
X7R, SMD
Capacitors
Kemet or
generic
C0603C104K5RACTU
14 1 C204
10 µF, 0603, 16 V, ±20 %,
X7R, SMD
Capacitor
Murata or
generic
GRM188R61C106MA73
15 1 C206
10 µF, 0603, 35 V, ±20 %,
X5R, SMD
Capacitor
Murata or
generic
GRM188R6YA106ME15D
16 3 C211-213
330 nF, 0603, 50 V, ±10 %,
X7R, SMD
Capacitors
TDK or
generic
C1608X7R1H334K080AC
TN1399
Bill of materials
TN1399 - Rev 1
page 16/26
